| Specification |
| Size | 383*283*85mm | Actual Power | 198W~209W |
| Input Voltage | AC100~240V | Output Current | 700mA |
| Output Voltage | DC32~45V | LED Quantity | 90pcs |
| Lifespan | 50,000 Hours | LED Type | 3W |
| Working Environment | -20~40℃,45%~95%RH | Color | Red(630nm)/Blue(460nm) |
| Working Frequency | 50~60Hz | Lumens | 3600lm |
| PAR | 310umol/1m 170/1.5m | LUX | 9450lux/1m 7200/1.5m |
| N.W. | 4.75kg | Lighting Area | 9.62m²/1m 21.2m²/1.5m |
| Inner Carton Size | 480*350*150mm | G.W.(Inner carton) | 5.3kg |
| Outer Carton Size | 540*480*360mm/4pcs | G.W.(Outer carton) | 23.5kg |
| Standard configuration | LED Light x1,Power line x1,Chaining x2 |
| Remarks | The above parameter is based on Red:Blue=8:1, for reference only |
Characteristics
1. 85 to 264V AC power input, 50/60HZ working frequency,suitable
for global residential energy environment.
2.Revolutionary heat dissipation design, availably alleviate the
internal thermal cycle, 10/15 Celsius lower than its precursor in
performance.
3.Intelligent monitor system, ensure the whole equipment in a good
working state.
4.Using advanced isolated power driver, UL standard output voltage
which is lower than 45V DC.Soft starting protection to avoid the
transient currents impact, effectively protecting the LEDs from
high voltage damage.
5.Aluminum face shield design, housing available for various
colors.
6.LED aquarium light is lighter and more convenient for
shipping,modular assembling very convenient fro maintaining.
7.Modular assembling, no glue and glass design, very easy for
repairment and maintenance.
8.New technology in fans will be more long-lasting,decreasing 50%
noise.
9.Built with optical lenses, the Penetration is more outstanding,
can be as much as 10-15 times powerful,available four options of
lenses -90 degree,120 degree .
10.Appearance features are also can be customized,available shell
colors:red,black,white.Face shield
colors:red,black,white,blue.Vents colors:red,black,white,grey.
11.Two power cords and two switchs.Separate control the blue and
white trips.
12.Using first rate LEDs as light source , ensuring the superior
high quality and long lifespan.
13.Customer can choose different ratios according to different
requirments.For the ratio,our suggestion is white:blue=1:1, use
interphase white and blue lights in fresh water, to provide the
hydrophytes and organisms light spectrum.
Attention
1.Do not use the lights in dripping water or anywhere where they
will get wet, water and electricity can be a dangerous mixture.
2.The working environment for LED aquarium light is
-20~40,45%RH~90%RH.
3.To protect the light, pls cut off the power when there is a
lightning strike.
4.Don’t touch or move when the light working.
